ESP32-S3

( number of products: 44 )

ESP32-S3 is a dual-core XTensa LX7 MCU, capable of running at 240 MHz. Apart from its 512 KB of internal SRAM, it also comes with integrated 2.4 GHz, 802.11 b/g/n Wi-Fi and Bluetooth 5 (LE) connectivity that provides long-range support. It has 45 programmable GPIOs and supports a rich set of peripherals. ESP32-S3 supports larger, high-speed octal SPI flash, and PSRAM with configurable data and instruction cache.

ESP32-S3 Main Features

AI Acceleration Support
ESP32-S3 has additional support for vector instructions in the MCU, which provides acceleration for neural network computing and signal processing workloads. Developers can take advantage of these vector instructions through ESP-DSP and ESP-NN libraries to optimize their applications. ESP-WHO and ESP-Skainet SDKs will also support this acceleration.

Wi-Fi + Bluetooth 5 (LE)
ESP32-S3 supports a 2.4 GHz Wi-Fi (802.11 b/g/n) with 40 MHz of bandwidth support. The Bluetooth Low Energy subsystem supports long range through Coded PHY and advertisement extension. It also supports higher transmission speed and data throughput, with 2 Mbps PHY. Both Wi-Fi and Bluetooth LE have superior RF performance that is maintained even at high temperatures.

Rich Set of IO Peripherals
ESP32-S3 has 45 programmable GPIOs, SPI, I2S, I2C, PWM, RMT, ADC and UART, SD/MMC host and TWAITM. In total, 14 GPIOs can be configured as capacitive touch input for HMI applications. Apart from all these peripherals, however, ESP32-S3 is also equipped with an ultra-low-power (ULP) core that supports multiple low-power modes in a variety of such use-cases.

Security
ESP32-S3 provides all the necessary security requirements for building securely connected devices, without requiring any external components. It supports AES-XTS-based flash encryption, RSA-based secure boot, digital signature and HMAC. ESP32-S3 also has a “World Controller” peripheral that provides two fully-isolated execution environments, which enables the implementation of a trusted-execution environment or a privilege-separation scheme.

Mature Software Support
ESP32-S3 is supported through Espressif’s popular ESP-IDF platform that already powers millions of devices on the market. ESP-IDF comes with rigorous testing, regular updates and an unparalleled support policy. Based on ESP-IDF’s mature software architecture, developers can easily build applications anew or migrate their own applications to the ESP32-S3 platform, and continue working with the trusted ESP-IDF tools and APIs.

ESP32-S3 series chips

32-bit MCU & 2.4 GHz Wi-Fi & Bluetooth 5 (LE)

32-bit dual-core Xtensa® LX7 processor operating at up to 240 MHz.
512 KB of SRAM and 384 KB of on-chip ROM, and SPI, Dual SPI, Quad SPI, Octal SPI, QPI and OPI interfaces that allow connection to flash memory and external RAM.
Additional support for vector instructions in the MCU, which provides acceleration of neural network calculations and signal processing.
Peripherals include 45 programmable GPIO, SPI, I2S, I2C, PWM, RMT, ADC and UART, SD/MMC host and TWAITM.
Reliable security features provided by RSA-based secure boot, AES-XTS-based flash encryption, innovative digital signature and HMAC "World Controller" peripherals.

ESP32-S3 series modules

32-bit MCU & 2.4 GHz Wi-Fi & Bluetooth 5 (LE)

32-bit dual-core Xtensa® LX7 processor operating at up to 240 MHz.
512 KB of SRAM and 384 KB of on-chip ROM, and SPI, Dual SPI, Quad SPI, Octal SPI, QPI and OPI interfaces that allow connection to flash memory and external RAM.
Additional support for vector instructions in the MCU, which provides acceleration of neural network calculations and signal processing.
Peripherals include 45 programmable GPIO, SPI, I2S, I2C, PWM, RMT, ADC and UART, SD/MMC host and TWAITM.
Reliable security features provided by RSA-based secure boot, AES-XTS-based flash encryption, innovative digital signature and HMAC "World Controller" peripherals.
Fully certified with integrated antenna and software stack.
