Variscite VAR-SOM-6UL Evaluation Kit

VAR-SOM-6UL is a highly flexible SoM/CoM series based on NXP's i.MX 6UltraLite / i.MX 6ULL / i.MX 6ULZ ARM Cortex-A7 processor with CPU clocking up to 900 MHz. The product is part of the Variscite VAR-SOM Pin2Pin family and provides a scalable, pin-compatible solution for i.MX6, i.MX8 / 8X /8M / 8M-Mini and i.MX 8M Nano-based platforms. Pin2Pin family products reduce project development time and costs incurred due to their efficiency.

The VAR-SOM-6UL provides a variety of interfaces and connectivity options - all with optimized power, size and price. Connectivity of the presented SoM includes 802.11b/g/n protocol or dual-band 802.11ac/a/b/g/n Wi-Fi, Bluetooth/BLE, dual Ethernet, dual USB, audio and camera input, parallel RGB, and LVDS display with touch panel and serial interfaces.

SoM's key features:

• WiFi 4 / BT 5.1 / Ethernet Cat5 Dual
• Operational temperature range: 0...+70°C
• Size: 67.5 x 33 x 4 mm
• CPU Clocking: 900 MHz
• Memory: 512 MB RAM / 512 MB NAND

The kit includes:

• SOM & Carrier board
• Debug Cable
• Antenna
• Boot/Rescue SD Card
• Display & Touch Panel
• Ethernet Cable
• 12V Power Supply
• Carrier Board Design Package
• Embedded operating system: Linux

The product includes the System-on-Module VAR-SOM-6UL in a stock version: VAR-SOM-6UL_Y2_900C_512R_05N_AC_EC_TP_LD_WB_CT. To order a SoM according to your own configuration, please contact us (applies to orders of more than 100 units).
