Variscite DART-MX8M Evaluation Kit w/ Android - evaluation board
TechnologyBT 5.2WiFi 5Ethernet Cat5e
ProcessorNXP i.MX8M Mini
RAM memory4 GB
eMMC memory16 GB
Product length in millimeters55
Product width in millimeters30
Operating systemAndroid
Evaluation boards displayYes
Longevityuntil 2033Details
Parametry
Find similar products
Brand
Symbol
VAR-DVK-DT8M_AO
Producer code
5900000834498
Series
Technology
BT 5.2
WiFi 5
Ethernet Cat5e
Processor
NXP i.MX8M Mini
CPU clocking (max)
1,5 GHz
Number of cores
4
RAM memory
4 GB
eMMC memory
16 GB
Product length in millimeters
55
Product width in millimeters
30
UART interfaces
4
I2C interfaces
3
SPI interfaces
3
USB interfaces
3.0/2.0 x 2
Operating system
Android
Evaluation boards display
Yes
Temperature range
0...+70°C
Voltage
3,4 - 4,5V
Longevity
until 2033
Variscite DART-MX8M Evaluation Kit w/ Android
DART-MX8M is a tiny 30mm x 55mm ARM SoM / CoM is based on NXP i.MX8M Quad 1.5GHz ARM Cortex-A53 plus 266MHz Cortex-M4. The high multimedia performance spec encompasses 4K video HEVC/H265/H264/VP9 decode with HDR, high-quality audio, 4K display support, 2D/3D graphics acceleration, with a variety of interfaces and connectivity options: Certified dual-band Wi-Fi 802.11 ac/a/b/g/n, BT 5.2/BLE, GbE, dual USB3, dual PCIe and UART.
- WiFi 5 / BT 5.2 / Ethernet Cat5e
- Operational temperature range: 0...+70°C
- SoM size: 55 x 30 x 4.7 mm
- CPU Clocking: 1.5 GHz
- Memory: 4 GB RAM / 16 GB eMMC
SoM's key features:
- SOM & Carrier board
- Debug Cable
- Antenna
- Boot/Rescue SD Card
- Display & Touch Panel
- Ethernet Cable
- 5V Power Supply
- Carrier Board Design Package
- Embedded operating system: Android
The kit includes:
The product includes the System-on-Module DART-MX8M in the stock version: DART-MX8MQ_1500C_4096R_16G_AC_EC_LD_WBD_CT. To order a SoM according to your own configuration, please contact us (applies to orders of more than 100 units).
