RAKwireless RAK5860

The RAK5860 expansion module is part of the WisBlock IO system and provides the ability to establish LTE CAT M1 and LTE NB2 type communications. Furthermore, the RAKwireless product also supports GNSS location.

RAK5860 can be programmed using Quectel AT commands.

Key features:

• Quectel BG77 with LTE Cat M1, LTE cat NB2, and GNSS
• Module size: 35 mm x 25 mm
• IPEX connectors for the LTE and GPS antenna
• Micro-USB connector
• Nano SIM and ESIM options
• Status Indication LEDs
• Power Supply: 2.6-4.2 V, typical supply voltage 3.3 V
