Powertip PH480272T016-ZHC01 - full viewing angle display
MatrixTFT
Screen diagonal (inch)4.3
Graphics display resolution standardWQVGA
Resolution (px)480 x 272
Touch panel typeCTP (borderless)
Luminance in cd/m2800
Controller (IC)Sitronix ST7283
Video interface24-bit RGBDetails
Parametry
Find similar products
Brand
Symbol
PH480272T016-ZHC01
Producer code
5900000824772
Matrix
TFT
Screen diagonal (inch)
4.3
Graphics display resolution standard
WQVGA
Resolution (px)
480 x 272
Aspect ratio
3:2
Touch panel type
CTP (borderless)
Luminance in cd/m2
800
Controller (IC)
Sitronix ST7283
Video interface
24-bit RGB
Viewing angles
80/80/80/80
Viewing direction
Full
Lens thickness
0,7 mm
Touch panel interface
I2C
Touch panel controller (IC)
Hycon HY4635
Temperature range
-20...+70°C
Voltage
3.3V
Powertip PH480272T016-ZHC01
A 4.3" TFT full viewing angle display with capacitive touch panel (CTP), created by Powertip. The display has a 480 x 272 WQVGA resolution and a 24 bit RGB interface. Brightness: 800. Operating temperature range -20...+70°C.
The product is part of 4-in-1 series, aiming to streamline display integration with the end product design by allowing the use of the same pin assignment and connector, with different sizes of displays (3.5″, 4.3″, 5.0″, 7.0"). The products in this series have high brightness and are available in touch panel and non-touch panel versions.
The photograph is for illustrative purposes only. To see the product, check the drawing in the gallery or download the documentation.
