Powertip PH192120T001-ZHC - full viewing angle display
Powertip PH192120T001-ZHC - full viewing angle display
Powertip PH192120T001-ZHC - full viewing angle display
Powertip PH192120T001-ZHC - full viewing angle display

Powertip PH192120T001-ZHC - full viewing angle display

MatrixTFT
Screen diagonal (inch)10.1
Graphics display resolution standardWUXGA
Resolution (px)1920 x 1200
Touch panel typeCTP
Luminance in cd/m2850
Controller (IC)FT5726
Video interfaceeDP
excl. VAT
14 days for easy returns
This product is not available in a stationary store
Safe shopping
Ask for this product
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.

Order a sample

Offer addressed to companies only. We will contact you within 48h.

Details

Parametry
Symbol
PH192120T001-ZHC
MatrixMatrix
TFT
Screen diagonal (inch)Screen diagonal (inch)
10.1
Graphics display resolution standardGraphics display resolution standard
WUXGA
Resolution (px)Resolution (px)
1920 x 1200
Aspect ratio
16:10
Touch panel typeTouch panel type
CTP
Luminance in cd/m2Luminance in cd/m2
850
Controller (IC)Controller (IC)
FT5726
Video interfaceVideo interface
eDP
Viewing angles
85/85/85/85
Viewing direction
Full
Temperature rangeTemperature range
-30...+85°C
Lens thickness
3 mm
VoltageVoltage
3.3V
Search

Powertip PH192120T001-ZHC

A 10.1" TFT full viewing angle display with capacitive touch display, created by Powertip. The display has 1900 x 1200 WUXGA resolution and eDP1.4 interface. Brightness: 800. Operating temperature range -30...+85°C.
