Powertip PH128800T007-ZHR03 - full viewing angle display
Powertip PH128800T007-ZHR03 - full viewing angle display
Powertip PH128800T007-ZHR03 - full viewing angle display
Powertip PH128800T007-ZHR03 - full viewing angle display

Powertip PH128800T007-ZHR03 - full viewing angle display

MatrixTFT
Screen diagonal (inch)10.1
Graphics display resolution standardWXGA
Resolution (px)1280 x 800
Touch panel typePCAP
Luminance in cd/m2800
Controller (IC)FT5726
Video interfaceLVDS
excl. VAT
14 days for easy returns
This product is not available in a stationary store
Safe shopping
Ask for this product
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.

Order a sample

Offer addressed to companies only. We will contact you within 48h.

Details

Parametry
Symbol
PH128800T007-ZHR03
Producer code
5900000832890
MatrixMatrix
TFT
Screen diagonal (inch)Screen diagonal (inch)
10.1
Graphics display resolution standardGraphics display resolution standard
WXGA
Resolution (px)Resolution (px)
1280 x 800
Aspect ratio
16:10
Touch panel typeTouch panel type
PCAP
Luminance in cd/m2Luminance in cd/m2
800
Controller (IC)Controller (IC)
FT5726
Video interfaceVideo interface
LVDS
Viewing angles
85/85/85/85
Viewing direction
Full
Lens thickness
3 mm
Temperature rangeTemperature range
-30...+80°C
VoltageVoltage
3.3V
Search

Powertip PH128800T007-ZHR03

A 10.1" TFT full viewing angle display with a PCAP capacitive touch panel, created by Powertip. The innovative PCAP panel is an advancement of the capacitive touch panels, allowing an unlimited number of simultaneous screen touches. The display has 1280 x 800 WXGA resolution and LVDS interface. Brightness: 1000. Operating temperature range -30...+80°C.
