Powertip PH128800T004-ZFC - HDMI display
Log in
Details
Parametry
Find similar products
Brand
Symbol
PH128800T004-ZFC
Matrix
TFT
Screen diagonal (inch)
10.1
Graphics display resolution standard
WXGA
Resolution (px)
1280 x 800
Aspect ratio
16:10
Touch panel type
CTP-GG
Luminance in cd/m2
450
Controller (IC)
None
Video interface
HDMI
Viewing angles
85/85/85/85
Viewing direction
Full
Temperature range
-20...+70°C
Touch panel controller (IC)
MXT1066T + SAM D21E
Touch panel interface
USB
Lens thickness
0,7 mm
Voltage
3.3V
Powertip PH128800T004-ZFC
A 10.1" TFT display with capacitive touch panel, created by Powertip. The display has 1280 x 800 WXGA resolution and HDMI interface. Brightness: 450. Operating temperature range -20...+70°C.
This product is NOT RECOMMENDED for new designs.
