Powertip PH102600T013-ZBC - HDMI display
Powertip PH102600T013-ZBC - HDMI display
Powertip PH102600T013-ZBC - HDMI display
Powertip PH102600T013-ZBC - HDMI display

Powertip PH102600T013-ZBC - HDMI display

MatrixTFT
Screen diagonal (inch)7
Graphics display resolution standardWSVGA
Resolution (px)1024 x 600
Touch panel typeCTP
Luminance in cd/m2650
Controller (IC)HY4635 + SAMD21
Video interfaceHDMI
Próbkitak
Size
uniwersalny
excl. VAT
Price on demandPrice on demand
14 days for easy returns
This product is not available in a stationary store
Safe shopping
Order a sample
Compare
Product data sheet - PH102600T013-ZBC01
Ask us about the product
Ask about the product
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.

Order a sample

Offer addressed to companies only. We will contact you within 48h.

Details

Parametry
Find similar products
Brand
Powertip
Symbol
PH102600T013-ZBC
MatrixMatrix
TFT
Screen diagonal (inch)Screen diagonal (inch)
7
Graphics display resolution standardGraphics display resolution standard
WSVGA
Resolution (px)Resolution (px)
1024 x 600
Aspect ratio
16:9
Touch panel typeTouch panel type
CTP
Luminance in cd/m2Luminance in cd/m2
650
Controller (IC)Controller (IC)
HY4635 + SAMD21
Video interfaceVideo interface
HDMI
Viewing direction
Full
Viewing angles
80/80/80/80
Temperature rangeTemperature range
-20...+70°C
VoltageVoltage
3.3V
Lens thickness
0,7 mm
Touch panel interface
USB
Search

Powertip PH102600T013-ZBC

A 7" TFT full viewing angle display, created by Powertip. The display has a 1024 x 600 WSVGA resolution and a HDMI interface. Brightness: 650. Operating temperature range -20...+70°C.
