Minew MS88SF3-1Y33AIR - BLE + IEEE 802.15.4 module
Antenna typePCB
FLASH memory512 KB
Product width in millimeters12.5
Product length in millimeters18.5
ChipNordic nRF52833
TechnologyBLE 5.0IEEE 802.15.4Log in
Details
Parametry
Find similar products
Brand
Symbol
MS88SF3-1Y33AIR
Producer code
5900000820859
Series
Antenna type
PCB
FLASH memory
512 KB
Product height in millimetres
2
Product width in millimeters
12.5
Product length in millimeters
18.5
GPIO
42
Voltage
1,7 - 3,6V
Temperature range
-40...+105°C
Chip
Nordic nRF52833
RAM memory
128 KB
CPU clocking (max)
64 MHz
Technology
BLE 5.0
IEEE 802.15.4
Minew MS88SF3-1Y33AIR
The MS88SF31 is a compact module designed by Minew, running on a powerful Nordic nRF52833 chip with a 32-bit ARM Cortex M4 processor and 512 KB FLASH + 128 KB RAM memory. The module supports Bluetooth 5.0 Low Energy and IEEE 802.15.4, it has 42 configurable pins, PCB antenna, and can operate in a temperature range of -40...+105℃. Power supply 1.7 - 3.6V. Dimensions: 18.5 × 12.5 × 2 mm.
