Euroclamp PV02-5-V - plug-in connector

Euroclamp PV02-5-V - plug-in connector

Number of pins2
Pitch (in milimetres)5
GenderMale
Rated current12A
Rated voltage250V
Size
uniwersalny
excl. VAT
0,06 €
gross
14 days for easy returns
Find out in which store you can check the product and buy it right away
Euroclamp PV02-5-V - plug-in connector
Euroclamp PV02-5-V - plug-in connector
uniwersalny
Safe shopping
Compare
Product Data Sheet - PV__-5-V
STEP 3D model - PV02-5-V
Ask us about the product
Ask about the product
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.

Order a sample

Offer addressed to companies only. We will contact you within 48h.

Details

Parametry
Find similar products
Brand
Euroclamp
Symbol
PV02-5-V
Producer code
5900000397542
Series
PV
Number of pinsNumber of pins
2
Pitch (in milimetres)
5
Gender
Male
Rated current
12A
Rated voltage
250V
Impulse voltage
4kV
Temperature rangeTemperature range
-40...+130°C
Flammability - UL Standard
UL 94 V-0
ColourColour
RAL 6032 - Green
Search

Euroclamp PV02-5-V

PV02-5-V is a male 2-pole plug-in connector, with a 5 mm pitch, made by Euroclamp. Can withstand a current of 12A, and 250V of maximum voltage, with 4kV withstanded impulse voltage. Operational temperature range: -40...+130°C.
