Espressif ESP8684-DevKitC-02C-N4 - development board
Espressif ESP8684-DevKitC-02C-N4 - development board
Espressif ESP8684-DevKitC-02C-N4 - development board
Espressif ESP8684-DevKitC-02C-N4 - development board

Espressif ESP8684-DevKitC-02C-N4 - development board

ChipESP8684H4X
ModuleESP8684-WROOM-02C
TechnologyBT 5.0WiFi 4
FLASH memory4 MB
Longevityuntil 2034
Antenna type
Size
uniwersalny
excl. VAT
9,23 €
gross
14 days for easy returns
Find out in which store you can check the product and buy it right away
Espressif ESP8684-DevKitC-02C-N4 - development board
Espressif ESP8684-DevKitC-02C-N4 - development board
Antenna type:PCB
uniwersalny
Safe shopping
Compare
Product data sheet - ESP8684-DevKitC-02
Ask us about the product
Ask for this product
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.

Order a sample

Offer addressed to companies only. We will contact you within 48h.

Details

Parametry
Find similar products
Brand
Espressif Systems
Symbol
ESP8684-DevKitC-02C-N4
Producer code
5900000857350
Series
ESP8684-DevKit
ChipChip
ESP8684H4X
ModuleModule
ESP8684-WROOM-02C
TechnologyTechnology
BT 5.0
WiFi 4
Product width in millimetersProduct width in millimeters
25.4
Product length in millimetersProduct length in millimeters
38.91
FLASH memoryFLASH memory
4 MB
SRAM in RTC memory
16 KB
ROM memory
576 KB
SRAM memorySRAM memory
272 KB
GPIOGPIO
14
Antenna typeAntenna type
PCB
VoltageVoltage
5V
Temperature rangeTemperature range
-40...+85°C
LongevityLongevity
until 2034
Search

Espressif ESP8684-DevKitC-02C-N4

A developement board by Espressif Systems, with an ESP8684-WROOM-02C module embedded, supporting WiFi 4, 2.4 GHz standards as well as Bluetooth 5, equipped with 14 configurable pins (GPIO) and a PCB antenna. Voltage is 5V.
