Variscite VAR-SOM-MX93 Evaluation Kit - evaluation board
Variscite VAR-SOM-MX93 Evaluation Kit - evaluation board
Variscite VAR-SOM-MX93 Evaluation Kit - evaluation board
Variscite VAR-SOM-MX93 Evaluation Kit - evaluation board

Variscite VAR-SOM-MX93 Evaluation Kit - evaluation board

TechnologyWiFi 5BT 5.2Ethernet Cat5e Dual
ProcessorNXP i.MX9352
RAM memory2 GB
eMMC memory16 GB
Product length in millimeters67.8
Product width in millimeters33
Evaluation boards displayYes
Operating systemLinux
Longevityuntil 2038
Size
uniwersalny
excl. VAT
313,27 €
gross
14 days for easy returns
This product is not available in a stationary store
Safe shopping
Compare
Product Data Sheet - VAR-SOM-MX93
Product Data Sheet - VAR-SOM-MX93 Evaluation Kit
Ask us about the product
Ask about the product
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.

Order a sample

Offer addressed to companies only. We will contact you within 48h.

Details

Parametry
Find similar products
Brand
Variscite
Symbol
VAR-DVK-VS93_LO
Producer code
5900000834450
Series
VAR-SOM
TechnologyTechnology
WiFi 5
BT 5.2
Ethernet Cat5e Dual
ProcessorProcessor
NXP i.MX9352
CPU clocking (max)CPU clocking (max)
1,7 GHz
Number of cores
2
RAM memoryRAM memory
2 GB
eMMC memoryeMMC memory
16 GB
Product length in millimetersProduct length in millimeters
67.8
Product width in millimetersProduct width in millimeters
33
SPI interfaces
3
I2C interfaces
5
UART interfaces
4
USB interfaces
2.0 x2
Evaluation boards displayEvaluation boards display
Yes
Operating systemOperating system
Linux
Temperature rangeTemperature range
0...+70°C
VoltageVoltage
3.3V
LongevityLongevity
until 2038
Search

Variscite VAR-SOM-MX93 Evaluation Kit

The i.MX 93 includes powerful dual Arm® Cortex®-A55 processors with speeds up to 1.7 GHz integrated with a NPU that accelerates machine learning inference. A general-purpose Arm® Cortex®-M33 running up to 250 MHz is for real-time and low-power processing. Robust control networks are possible via CAN-FD interface. Also, dual 1 Gbps Ethernet controllers, one supporting Time Sensitive Networking (TSN), drive gateway applications with low latency.

    SoM's key features:

  • WiFi 5 / BT 5.2 / Ethernet Cat5e Dual
  • Operational temperature range: 0...+70°C
  • SoM size: 67.8 x 33 mm
  • CPU Clocking: 1.7 GHz
  • Memory: 2 GB RAM / 16 GB eMMC

    The kit includes:

  • SOM & Carrier board
  • Debug Cable
  • Antenna
  • Boot/Rescue SD Card
  • 7″ WVGA Display & Touch Panel
  • Ethernet Cable
  • 12V Power Supply
  • Carrier Board Design Package
  • Heat sink
  • Embedded operating system: Linux

The product includes the System-on-Module VAR-SOM-MX93 in a stock version. To order a SoM according to your own configuration, please contact us (applies to orders of more than 100 units).
