Variscite SPEAR-MX8 - SoM module
TechnologyBT 5.2WiFi 5Ethernet Cat5e Dual
ProcessorNXP iMX 8QuadMaxNXP iMX 8QuadPlus
Product length in millimeters68
Product width in millimeters55
Longevityuntil 2034Log in
Details
Parametry
Find similar products
Brand
Symbol
SPEAR-MX8
Series
Technology
BT 5.2
WiFi 5
Ethernet Cat5e Dual
Processor
NXP iMX 8QuadMax
NXP iMX 8QuadPlus
CPU clocking (max)
1,6 GHz
Number of cores
5
6
RAM memory
2 GB
4 GB
8 GB
eMMC memory
8 GB
16 GB
32 GB
64 GB
128 GB
Product length in millimeters
68
Product width in millimeters
55
UART interfaces
5
I2C interfaces
4
SPI interfaces
4
USB interfaces
3.0/2.0 x 1
1x 2.0
Operating system
Android
Linux
Temperature range
-25...+85°C
-40...+85°C
Voltage
3,4 - 4,5V
Longevity
until 2034
Variscite SPEAR-MX8
The SPEAR-MX8 high-performance computer supports 4K UltraHD display, HQ audio, 2D/3D acceleration, camera connector and HDMI. In addition, the SoM supports dual-band Wi-Fi 802.11ac/a/b/g/n, BT/BLE, dual GbE, dual USB3, PCIe, SATA III, CAN FD, SPI and UART.
The parameters available in the configurator define the SoM's configuration options. To order a SoM according to your own configuration, please contact us (applies to orders of more than 100 units).
