Powertip PH800480T030-ZHR06 5'' - full-view display
Powertip PH800480T030-ZHR06 5'' - full-view display
Powertip PH800480T030-ZHR06 5'' - full-view display
Powertip PH800480T030-ZHR06 5'' - full-view display

Powertip PH800480T030-ZHR06 5'' - full-view display

MatrixTFT
Screen diagonal (inch)5
Resolution (px)800 x 480
Graphics display resolution standardWVGA
Touch panel typeCTP
Luminance in cd/m2850
Controller (IC)Sitronix ST7262
Próbkitak
Size
uniwersalny
excl. VAT
Price on demandPrice on demand
14 days for easy returns
This product is not available in a stationary store
Safe shopping
Order a sample
Compare
Datasheet - Powertip PH800480T030-ZHR06
Ask us about the product
Ask for this product
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.

Order a sample

Offer addressed to companies only. We will contact you within 48h.

Details

Parametry
Find similar products
Brand
Powertip
Symbol
PH800480T030-ZHR06
MatrixMatrix
TFT
Screen diagonal (inch)Screen diagonal (inch)
5
Resolution (px)Resolution (px)
800 x 480
Graphics display resolution standardGraphics display resolution standard
WVGA
Aspect ratio
5:3
Touch panel typeTouch panel type
CTP
Luminance in cd/m2Luminance in cd/m2
850
Controller (IC)Controller (IC)
Sitronix ST7262
Video interfaceVideo interface
Parallel RGB
SPI
Viewing angles
80/80/80/80
Temperature rangeTemperature range
-20...+70°C
VoltageVoltage
3,3V
Lens thickness
3 mm
Touch panel controller (IC)Touch panel controller (IC)
Hycon HY4635
Touch panel interface
I2C
Search

Powertip PH800480T030-ZHR06 5"

TFT display with 800 x 480 WVGA resolution with full viewing angle, 5" diagonal,with Parallel RGB and SPI video interface and capacitive touch screen (CTP), lens thickness 3 mm. Brightness: 850. operating temperature range -20...+70°C. Sitronix ST762 controller. Applications: EV charger, measurement device, drone controller, solar energy controller.
