Powertip PH480272T017-ZBA02, 4.3” - full-view display
MatrixTFT
Screen diagonal (inch)4.3
Resolution (px)480 x 272
Graphics display resolution standardWQVGA
Luminance in cd/m2400
Controller (IC)NV3041A-01
Touch panel typeNone
Video interfaceParallel 8/ 9/ 16-bit series 8080 SPIDetails
Parametry
Find similar products
Brand
Symbol
PH480272T017-ZBA02
Matrix
TFT
Screen diagonal (inch)
4.3
Resolution (px)
480 x 272
Graphics display resolution standard
WQVGA
Luminance in cd/m2
400
Aspect ratio
1.76
Controller (IC)
NV3041A-01
Touch panel type
None
Video interface
Parallel 8/ 9/ 16-bit series 8080
SPI
Viewing angles
80/80/80/80
Voltage
4.6V
Temperature range
-20...+70°C
Lens thickness
2.9 mm
Powertip PH480272T017-ZBA02, 4.3”
TFT full-view 4.3" display with SPI and 8, 9, 16-bit parallel interface from 8080 series. Brightness: 400, NV3041A-01 controller. Operating temperature range -20...+70°C.
Applications: home security, digital queuing system, credit card reader, management device.
