Powertip PH480272T016-ZHR - full viewing angle display
Powertip PH480272T016-ZHR - full viewing angle display
Powertip PH480272T016-ZHR - full viewing angle display
Powertip PH480272T016-ZHR - full viewing angle display

Powertip PH480272T016-ZHR - full viewing angle display

MatrixTFT
Screen diagonal (inch)4.3
Graphics display resolution standardWQVGA
Resolution (px)480 x 272
Touch panel typePCAP
Luminance in cd/m2850
Controller (IC)SC7283-G4
Video interfaceSPIRGB 24-bit
Próbkitak
Size
uniwersalny
excl. VAT
Price on demandPrice on demand
14 days for easy returns
This product is not available in a stationary store
Safe shopping
Order a sample
Compare
Datasheet - PH480272T016-ZHR
Ask us about the product
Ask about the product
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.

Order a sample

Offer addressed to companies only. We will contact you within 48h.

Details

Parametry
Find similar products
Brand
Powertip
Symbol
PH480272T016-ZHR
MatrixMatrix
TFT
Screen diagonal (inch)Screen diagonal (inch)
4.3
Graphics display resolution standardGraphics display resolution standard
WQVGA
Resolution (px)Resolution (px)
480 x 272
Aspect ratio
3:2
Touch panel typeTouch panel type
PCAP
Luminance in cd/m2Luminance in cd/m2
850
Controller (IC)Controller (IC)
SC7283-G4
Video interfaceVideo interface
SPI
RGB 24-bit
Viewing angles
80/80/80/80
Viewing direction
Full
Touch panel controller (IC)Touch panel controller (IC)
Hycon HY4635
Temperature rangeTemperature range
-20...+70°C
VoltageVoltage
3,0 - 3,6V
Search

Powertip PH480272T016-ZHR

A 4.3" TFT full viewing angle display with capacitive touch panel (CTP), created by Powertip. The display has a 480 x 272 WQVGA resolution and a parallel RGB interface. Brightness: 420. Operating temperature range -20...+70°C.

pixel
