Powertip PH480272T016-ZFA - full viewing angle display
Powertip PH480272T016-ZFA - full viewing angle display
Powertip PH480272T016-ZFA - full viewing angle display
Powertip PH480272T016-ZFA - full viewing angle display

Powertip PH480272T016-ZFA - full viewing angle display

MatrixTFT
Screen diagonal (inch)4.3
Graphics display resolution standardWQVGA
Resolution (px)480 x 272
Touch panel typeNone
Luminance in cd/m2550
Controller (IC)SC7283-G4
Video interfaceSPIParallel RGB
Size
uniwersalny
excl. VAT
Price on demandPrice on demand
14 days for easy returns
This product is not available in a stationary store
Safe shopping
Compare
Product Data Sheet - PH480272T016-ZFA
Ask us about the product
Ask for this product
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.

Order a sample

Offer addressed to companies only. We will contact you within 48h.

Details

Parametry
Find similar products
Brand
Powertip
Symbol
PH480272T016-ZFA
MatrixMatrix
TFT
Screen diagonal (inch)Screen diagonal (inch)
4.3
Graphics display resolution standardGraphics display resolution standard
WQVGA
Resolution (px)Resolution (px)
480 x 272
Aspect ratio
3:2
Touch panel typeTouch panel type
None
Luminance in cd/m2Luminance in cd/m2
550
Controller (IC)Controller (IC)
SC7283-G4
Video interfaceVideo interface
SPI
Parallel RGB
Viewing angles
80/80/80/80
Viewing direction
Full
Temperature rangeTemperature range
-20...+70°C
VoltageVoltage
3.3V
Lens thickness
No data
Search

Powertip PH480272T016-ZFA

A 4.3" TFT full viewing angle display, created by Powertip. The display has a 480 x 272 WQVGA resolution and a SPI and Parallel RGB interface. Brightness: 550. Operating temperature range -20...+70°C.
