Powertip PH480272T009-IHC07 - CTP display
Powertip PH480272T009-IHC07 - CTP display
Powertip PH480272T009-IHC07 - CTP display
Powertip PH480272T009-IHC07 - CTP display

Powertip PH480272T009-IHC07 - CTP display

MatrixTFT
Screen diagonal (inch)4.3
Graphics display resolution standardWQVGA
Resolution (px)480 x 272
Touch panel typeCTP (borderless)
Luminance in cd/m2850
Controller (IC)Ilitek ILI6480B
Video interfaceRGB 24-bit
excl. VAT
14 days for easy returns
This product is not available in a stationary store
Safe shopping
Ask about the product
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.

Order a sample

Offer addressed to companies only. We will contact you within 48h.

Details

Parametry
Symbol
PH480272T009-IHC07
MatrixMatrix
TFT
Screen diagonal (inch)Screen diagonal (inch)
4.3
Graphics display resolution standardGraphics display resolution standard
WQVGA
Resolution (px)Resolution (px)
480 x 272
Aspect ratio
5:3
Touch panel typeTouch panel type
CTP (borderless)
Luminance in cd/m2Luminance in cd/m2
850
Controller (IC)Controller (IC)
Ilitek ILI6480B
Video interfaceVideo interface
RGB 24-bit
Viewing angles
60/60/60/60
Viewing direction
6H
Temperature rangeTemperature range
-20...+70°C
VoltageVoltage
3.3V
Lens thickness
0,7 mm
Touch panel interface
I2C
Touch panel controller (IC)Touch panel controller (IC)
Hycon HY4635
Search

Powertip PH480272T009-IHC07

A 4.3" TFT display with a capacitive touch panel, created by Powertip. The display has 480 x 272 WQVGA resolution and 24-bit RGB interface. Brightness: 850. Operating temperature range -20...+70°C.
