Powertip PH320240T028-ZEC03 - full viewing angle display
Powertip PH320240T028-ZEC03 - full viewing angle display
Powertip PH320240T028-ZEC03 - full viewing angle display
Powertip PH320240T028-ZEC03 - full viewing angle display

Powertip PH320240T028-ZEC03 - full viewing angle display

MatrixTFT
Screen diagonal (inch)3.5
Graphics display resolution standardLQVGA
Resolution (px)320 x 240
Touch panel typeCTP
Luminance in cd/m2230
Controller (IC)Sitronix ST7272A
Video interface24-bit RGB
Size
uniwersalny
excl. VAT
Price on demandPrice on demand
14 days for easy returns
This product is not available in a stationary store
Safe shopping
Compare
Product Data Sheet - PH320240T028-ZEC03
Ask us about the product
Ask for this product
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.

Order a sample

Offer addressed to companies only. We will contact you within 48h.

Details

Parametry
Find similar products
Brand
Powertip
Symbol
PH320240T028-ZEC03
Producer code
5900000824642
MatrixMatrix
TFT
Screen diagonal (inch)Screen diagonal (inch)
3.5
Graphics display resolution standardGraphics display resolution standard
LQVGA
Resolution (px)Resolution (px)
320 x 240
Aspect ratio
4:3
Touch panel typeTouch panel type
CTP
Luminance in cd/m2Luminance in cd/m2
230
Controller (IC)Controller (IC)
Sitronix ST7272A
Video interfaceVideo interface
24-bit RGB
Viewing angles
80/80/80/80
Viewing direction
Full
Lens thickness
0,7 mm
Touch panel controller (IC)Touch panel controller (IC)
Chipone ICNT8952
Touch panel interface
I2C
Temperature rangeTemperature range
-20...+70°C
VoltageVoltage
3.3V
Search

Powertip PH320240T028-ZEC03

A 3.5" TFT full viewing angle display with capacitive touch panel (CTP), created by Powertip. The display has a 320 x 240 LQVGA resolution and a 24 bit RGB interface. Brightness: 230. Operating temperature range -20...+70°C.
