Powertip PH240320T075-ZEA04 - full viewing angle display
MatrixTFT
Screen diagonal (inch)2.8
Graphics display resolution standardQVGA
Resolution (px)240 x 320
Touch panel typeNone
Luminance in cd/m2350
Controller (IC)ST7789T3-G4-1
Video interfaceParallel 8/ 9/ 16-bit series 8080 Details
Parametry
Find similar products
Brand
Symbol
PH240320T075-ZEA04
Matrix
TFT
Screen diagonal (inch)
2.8
Graphics display resolution standard
QVGA
Resolution (px)
240 x 320
Aspect ratio
4:3
Touch panel type
None
Luminance in cd/m2
350
Controller (IC)
ST7789T3-G4-1
Video interface
Parallel 8/ 9/ 16-bit series 8080
Viewing angles
80/80/80/80
Viewing direction
Full
Temperature range
-20...+70°C
Voltage
2,8V
Lens thickness
No data
Powertip PH240320T075-ZEA04
A 2.8" TFT full viewing angle display, created by Powertip. The display has a 240 x 320 QVGA resolution and an 16-bit 8080 interface. Brightness: 350. Operating temperature range -20...+70°C.
