Powertip PH240320T-062-L-Q - TFT display
Powertip PH240320T-062-L-Q - TFT display
Powertip PH240320T-062-L-Q - TFT display
Powertip PH240320T-062-L-Q - TFT display

Powertip PH240320T-062-L-Q - TFT display

MatrixTFT
Screen diagonal (inch)2.4
Graphics display resolution standardQVGA
Resolution (px)240 x 320
Touch panel typeNone
Luminance in cd/m2120
Controller (IC)ILI9341
Video interfaceParallel 8080 8-bit
Size
uniwersalny
excl. VAT
Price on demandPrice on demand
14 days for easy returns
This product is not available in a stationary store
Safe shopping
Compare
Product Data Sheet - PH240320T-062-L-Q
Ask us about the product
Ask about the product
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.

Order a sample

Offer addressed to companies only. We will contact you within 48h.

Details

Parametry
Find similar products
Brand
Powertip
Symbol
PH240320T-062-L-Q
MatrixMatrix
TFT
Screen diagonal (inch)Screen diagonal (inch)
2.4
Graphics display resolution standardGraphics display resolution standard
QVGA
Resolution (px)Resolution (px)
240 x 320
Aspect ratio
4:3
Touch panel typeTouch panel type
None
Luminance in cd/m2Luminance in cd/m2
120
Controller (IC)Controller (IC)
ILI9341
Video interfaceVideo interface
Parallel 8080 8-bit
Viewing angles
60/60/60/60
Viewing direction
12H
Temperature rangeTemperature range
-20...+70°C
Lens thickness
0,6 mm
VoltageVoltage
2,8V
Search

Powertip PH240320T-062-L-Q

A 2.4" TFT display, created by Powertip. The display has a 240 x 320 QVGA resolution and an 80-8 bit interface. Brightness: 120. Operating temperature range -20...+70°C.
