Espressif ESP32-DevkitM-1U - development board
Details
Parametry
Find similar products
Brand
Symbol
ESP32-DevkitM-1U
Producer code
5900000820613
Chip
ESP32-U4WDH
Module
ESP32-MINI-1U
Technology
BT 4.2
WiFi 4
Temperature range
-40...+85°C
Product width in millimeters
25.4
Product length in millimeters
44.35
FLASH memory
4 MB
SRAM in RTC memory
16 KB
ROM memory
448 KB
SRAM memory
520 KB
GPIO
28
Antenna type
IPEX
Voltage
3,0 - 3,6V
Longevity
until 2028
Espressif ESP32-DevkitM-1U
A developement board by Espressif Systems, with an ESP32-MINI-1U module embedded, supporting WiFi 802.11 b/g/n, 2.4 GHz standards as well as Bluetooth 4.2, equipped with 28 configurable pins (GPIO) and an IPEX antenna.
The module can operate in temperature range of -40... +85°C, and it's power supply is 3.0 - 3.6.
